ENA broad batch range can be processed in the same drum.
PERFIMA
CoatingFlexible film and sugar coating with a perforated pan. PERFIMA combines controlled mixing and drying with containment options for demanding pharmaceutical applications.
Designed around your process
Coating
The pan and baffle arrangement maintain core movement across a broad working range, from 25% to 100% of drum capacity. Automatic loading, discharge and cleaning options support repeatable operation. Configurations for tablets, minitablets and pellets allow the system to be matched to the product and containment needs.
Tailored to your application
Technology with local support
From choosing the right configuration to coordinating a quotation, the EZ GMP automation team connects your production requirements with the appropriate manufacturer specialists.
Tell us about your product, batch size, packaging format and facility. We’ll help define the next steps for your project in Vietnam.
PERFIMA — Highlights
Airflow and mixing are designed for even coating and drying.
Containment configurations reduce operator exposure to potent products.
Through-wall installation and automatic handling options support line integration.
Technical information
Swipe the table to compare models
| PERFIMA technical data | ||||||
|---|---|---|---|---|---|---|
| Model | Lab* | 200 (120) | 200 | 500 (360) | 500 | 800 |
| Minimum/maximum capacity (litres) | 6 (1.5 – 6)10 (3-10)30 (8-30)70 (18-70) | 30-120(12-120)** | 60-250(25-250)** | 90-360(30-360)** | 140-550(55-550)** | 240-950(95-950)** |
| Pan diameter (mm) | 715 (for 6 L drum)765 (for 10 l drum)865 (for 30 l drum)985 (for 70 l drum) | 1,200 | 1,360 | 1,516 | 1,716 | 1,985 |
| Pan mouth diameter (mm) | 474 | 540 | 540 | 580 | 580 | 732 |
| Pan motor power (kW) | 1.5 | 4 | 4 | 5.5 | 5.5 | 7.5 |
| Process air delivery (m³/h) | 1,100 | 2,500 | 4,000 | 5,000 | 6,000 | 8,000 |
| DIMENSION | LAB | 200 | 500 | 800 |
|---|---|---|---|---|
| A (mm) | 1,895 | 2,824 | 3,833 | 4,624 |
| B (mm) | 1,594 | 1,824 | 2,300 | 2,831 |
| C (mm) | 1,250 | 1,801 | 2,201 | 2,635 |
| D (mm) | 2,840 | 3,775 | 4,896 | 6,047 |
| E (mm) | 928 | 852 | 947 | 1,012 |
| F (mm) | 2,532 | 2,671 | 2,961 | 3,257 |
| G (mm) | 1,997 | 2,082 | 2,370 | 2,670 |
| H (mm) | 1,400 | 1,340 | 1,435 | 1,600 |
Published manufacturer specifications. Actual output depends on product characteristics, format and selected configuration.
Manufacturer reference: IMA ACTIVE
