ARIA

Name: ARIA
Brand: IMA ACTIVE

Fluid Bed Processing

Drying, granulation and pellet coating in a flexible fluid-bed system. ARIA supports contained product transfer and integration with upstream granulation equipment.

Enquire

Designed around your process

Fluid Bed Processing

Designed for through-wall installation, ARIA offers filter and product-handling arrangements to suit the process. Accessible filters and removable air distributors simplify inspection. Water recirculation and air-handling recovery options help manage utility consumption.

Tailored to your application

Technology with local support

From choosing the right configuration to coordinating a quotation, the EZ GMP automation team connects your production requirements with the appropriate manufacturer specialists.

Tell us about your product, batch size, packaging format and facility. We’ll help define the next steps for your project in Vietnam.

ARIA — Highlights

Drying, granulation and pellet coating share one processing platform.

Contained loading and discharge options support potent-product applications.

Multiple filter types adapt the equipment to the process.

Air distributors can be cleaned in place and removed for inspection.

Technical information

Swipe the table to compare models

ARIA — Specifications
ARIA technical data
Model	60	120	300	600	900	1200	1500	2000
Recommended batch size (kg)	25	50	120	250	400	500	600	800
Roto Mix inline (l)	60	120	300	600	900	1,200	1,500	2,500

ARIA — Specifications 2
ARIA dimensions
Model	60	120	300	600	900	1200	1500	2000
A (mm)	590	700	960	1,190	1,410	1,740		1,740	1,740	1,800
B (mm)	1,150	1,260	1,520	1,750	2,040	2,300		2,300	2,300	2,800
C (mm)	2,500	2,790	3,235	3,615	4,100	5,670		5,670	5,670	6,300
D (mm)	1,775	1,775	1,840	2,220	2,675	3,785		3,785	3,785	3,800
E (mm)	1,010	1,010	1,050	1,360	1,530	1,900		1,900	1,900	2,150
F (mm)	1,420	1,420	1,560	1,610	1,830	2,160		2,160	2,160	2,600
